KOMUNICA KP-2201 EARPHONE SET

The Komunica KP-2201-IL is a headset with a microphone and single earpiece, designed for handheld radios with an Icom-type 2-pin connector. The rotatable ear clip allows the earpiece to be used on either the right or left ear, and the reinforced cable and clothing-attachable microphone make it suitable for daily communications during hunting, at work, and at events.

Suitable for use with

• Handheld radios with Icom 2-pin connectors

• Compatible Alinco and President radios

• Radio communication during hunting

• Security and surveillance work

• Event organization

• Hotels and service industries

• Industrial and warehouse work

• Hospitals and care institutions

• More discreet listening to radio messages

• Hands-free listening

• Wearing on the left or right ear

• For users who do not want radio messages to play over a loudspeaker

• Long-term use in shifts

Why choose the Komunica KP-2201-IL?

• Icom-type 2-pin plug

• Behind-the-ear earpiece

• Rotatable ear clip

• Usable on left or right ear

• Fits ears of different sizes

• Electret microphone

• Omnidirectional microphone pickup

• Microphone frequency range 100 Hz to 10 kHz

• Metal clip for attaching to clothing

• Microphone clip rotates 360°

• Reinforced connection cable

• Audio part designed for clear voice transmission and reception

• Earpiece nominal power 10 mW

• Earpiece maximum input power 20 mW

• Wide operating temperature –20 to +55 °C

• Simple and lightweight daily communication solution

Technical specifications

• Manufacturer: Komunica

• Product type: handheld radio headset with microphone and earpiece

• Connection: Icom-type 2-pin plug

• Earpiece type: single-sided earpiece with ear clip

• Wearing style: right or left ear

• Ear clip: rotatable and adjustable

• Cable: reinforced

• Microphone: electret microphone

• Microphone directivity: omnidirectional

• Microphone frequency range: 100 Hz to 10 kHz

• Microphone sensitivity: –42 dB ± 3 dB at 1 kHz

• Microphone impedance: up to 2 kΩ

• Microphone operating voltage: 1–10 V

• Microphone operating temperature: –20 to +55 °C

• Earpiece sensitivity: 80 dB ± 3 dB at 1 kHz

• Earpiece nominal impedance: 32 Ω ± 15%

• Earpiece nominal input power: 10 mW

• Earpiece maximum input power: 20 mW

• Earpiece distortion: up to 5% in the frequency range 100 Hz to 5 kHz at 1 mW

• Earpiece operating temperature: –20 to +55 °C

• Microphone attachment: 360° rotatable metal clip

• Color: black

Known compatibility

According to the manufacturer and distributors, the headset is compatible with, among others, the following Icom radios:

• Icom F3G

• Icom F3GS

• Icom F4G

• Icom F4GS

• Icom F11

• Icom F11S

• Icom F33G

• Icom F43G

• Icom F21BR

• Icom F21GM

• Icom F24S

• Icom F3021

• Icom F4021

The seller's database also lists models Alinco DJ-A11, DJ-A41, and DJ-MD5, as well as President Randy 3. Compatibility should always be checked according to the specific radio's user manual, plug shape, and contact arrangement.

Included in the set

• Komunica KP-2201-IL earpiece with ear clip

• Integrated electret microphone

• Metal clip for attaching to clothing

• Icom-type 2-pin connection cable

The radio and other accessories shown in the pictures are not included.

Frequently Asked Questions

Is the Komunica KP-2201-IL compatible with all Icom radios?

No. Icom uses several types of accessory jacks on different models. The headset is only compatible with devices whose plug shape, contact spacing, and electrical connection match the KP-2201-IL Icom 2-pin interface.

Can the earpiece be worn on both ears?

Yes. The rotatable ear clip can be adjusted for use on either the right or left ear. The clip adapts to ears of different sizes.

Does the set include a microphone?

Yes. The headset has an omnidirectional electret microphone that attaches to clothing. The microphone clip can be rotated up to 360° to position the cable and microphone as needed.

Is this a noise-cancelling headset?

No. This is a simple communication set with one earpiece and microphone. The manufacturer does not describe it as having active noise cancellation or as a hearing protection device.

Does the headset protect hearing from gunshots?

No. The earpiece is not certified for hearing protection. When hunting or at the shooting range, separate active or passive hearing protectors with appropriate attenuation ratings must be used.

Does the Icom-type 2-pin plug automatically fit Kenwood 2-pin sockets?

No. Two-pin plugs may look similar on the outside, but the contact spacing, diameter, and electrical connection may differ. The plug should not be forced into an incompatible socket.

Can the headset be used in the rain?

The manufacturer's technical specifications do not indicate a water resistance rating for the headset. Therefore, the microphone, earpiece, and plug should be protected from heavy rain, water, and prolonged moisture.

When is the Komunica KP-2201-IL the right choice?

The KP-2201-IL is suitable for users who need a simple and lightweight single-ear headset for a handheld radio with an Icom-type 2-pin connector. The rotatable ear clip is practical when users change or when the earpiece needs to be worn on different ears.

In noisy environments, an acoustic tube earpiece or a professional headset with stronger sound isolation may provide better voice clarity. For hunting and at the shooting range, certified hearing protection with radio capability should be preferred, as the KP-2201-IL does not reduce the risk of hearing damage from gunshots.

Recommendations

We recommend checking the exact model of your radio and accessory socket before purchase. The term “Icom 2-pin” does not mean the headset is compatible with all Icom devices. Compare plug diameter, spacing, and the accessory code shown in your radio’s manual.

Make a test call before using it outdoors. Attach the microphone to your chest or collar so that it stays close to your mouth but does not rub against your jacket, scarf, or gear. The omnidirectional microphone picks up sound from multiple directions, so strong wind or clothing movement may reduce voice clarity.

Insert and remove the plug with the radio switched off, holding the plug body, not the cable. Avoid sharply bending the wire near the plug and microphone. After use in damp conditions, allow the set to dry at room temperature before storage.

Simple Icom 2-pin headset for everyday radio communication

The Komunica KP-2201-IL combines a rotatable ear clip, electret microphone, reinforced cable, and Icom-type 2-pin interface. It is a practical choice for hunting, security work, events, and other situations where you want to listen to radio messages more discreetly and keep your hands free.
